Single Girder Bridge Crane

PRODUCT

S.G. Type EOT Crane with Electric Wire Rope Hoist

QUANTITY

01 Nos

CAPACITY

10 Ton

SPAN

13250 MM

LIFT

8 MTR

LT

60 FT

APPLICATION

Indoor

DUTY

Class II As per IS: 3177 / IS: 807

OPERATIONS

Through hanging pendant push-button station

SPEED MAIN HT

SPEED LT

SPEED CT

3 4 MPM

15 16 MPM

8 10 MPM

MOTOR

All main motor are SQ. Cage Induction, Foot Mounted, Face Mounted, and Flange Mounted Crane Duty Motor.

Make: STALLION

MOTOR HOIST

MOTOR HP LT

MOTOR HP CT

12.5 HP X 01 Nos.

1 HP X 02 Nos.

1.5 HP X 01 Nos.

ALL BRAKE

AC DISC TYPE BRAKE Make : Our make/Gmac

WIRE ROPE

16 MM DIA X 4 Falls,

6 X 36 Construction, Fiber Core, 180 kg/mm2 Braking Strength

R.H. Lay, Un-galvanized Steel Wire Rope as per IS: 2266.

Make: USHA Martin

ROPE DRUM

270 MM Diameter, Made from Seamless Pipe

CROSS TRAVELS

C RAIL FESTOON

FIXED CABLES

PVC/PVC unarmored Cable Running In the trays or fixed to Bridge

PULLEY/SHEAVE

All Pulleys are M.S Fabrication and duly Machined as per IS3177

HOOK

Standard C Type Hook as Per IS 3815 / IS 15560

C.T WHEEL

L.T WHEEL

GR/PR wheel

200 MM Dia. X 4 Nos. Forged Steel EN-8 Toughened

BEARINGS

As Per Standard

Hoist Limit Switch

Roller Type

MAIN GIRDER

BOX GIRDER FABRICATED

CONTROL PANEL

Our own make with BCH/ Schneider make components. It consisting of all the switch gear items which are necessary for the satisfactory operation of the EOT Crane. (ALL MOTION DRIVE PANEL)

CONTROL VOLTAGE

110 Volts

SUPPLY

3 Phase, 415 Volts + / - 10%, 50% CDF

END CARRAIGE

L BLOCK END CARRIAGE

BUFFERS

Rubber Buffers shall be provided

PENDANT

Up / Down, Front / Back, Left / Right Push Buttons, Make: Own

TESTING

100% Load Test & Overload Test will be done at your site

CABLE

Rubicon/Bch Cable

GEAR BOX (HT & CT)

GEAR BOX ( LT )

Helical Type, Make: LAXMI ENGINEERING

Helical Type, Make: PREMIUM TRANSMISSION

VFD

ALL MOTION VFD DRIVE (SCNEIDER MAKE)
